FEC15/FEC15W
产品简介：
台湾博大P-DUKE FEC15(FEC15W)系列DC/DC电源模块,输入电压:12V/24V/48V ,输出电压:3.3V/5V/12V/15V/ ±5V/±12V/±15V ,输出功率13.2-15.3W,效率达88%,工作温度范围-40℃至85℃(FEC15),-40℃至105℃(FEC15W).
产品详细：
台湾博大P-DUKE FEC15(FEC15W)系列DC/DC电源模块
输入电压:12V/24V/48V
输出电压:3.3V/5V/12V/15V/ ±5V/±12V/±15V
输出功率13.2-15.3W,效率达88%
2:1(FEC15),4:1(FEC15W)输入电压范围,遥控功能
工作频率500KHZ(单路输出),300KHZ(双路输出)
内置∏滤波器
过电压和连续短路保护
工作温度范围-40℃至85℃(FEC15),-40℃至105℃(FEC15W)
输入输出隔离电压1600VDC
MTBF达2.041*106时
金属外壳绝缘底座,六面EMI/RFI屏蔽
UL,TUV,CB和CE安全认证
外型尺寸:50.8mm(长)x25.4mm(宽)x10.2mm(高)
- 输入电压:9-18V
18-36V(9-36V)
36-75V(18-75V)
- 输出电压:3.3V/5V/12V/
15V/±5V/
±12V/±15V
- 输出功率:13.2-15W
- 尺 寸:50.8*25.4*10.2
资料 资料
| 型号 |
标准输入 |
输入电压(V) |
效率(%) |
输出组数 |
输出电压(V) |
输出电流(A) |
输出功率(W) |
工作温度 |
尺寸(mm) |
| FEC15-12D05 | 12 | 9~18 | 83 | 2 | 5/-5 | 1.5 | 15 | -40~+85℃ | 50.8*25.4*10.2 |
| FEC15-12D12 | 12 | 9~18 | 86 | 2 | 12/-12 | 0.625 | 15 | -40~+85℃ | 50.8*25.4*10.2 |
| FEC15-12D15 | 12 | 9~18 | 84 | 2 | 15/-15 | 0.5 | 15 | -40~+85℃ | 50.8*25.4*10.2 |
| FEC15-12S05 | 12 | 9~18 | 82 | 1 | 5/0 | 3 | 15 | -40~+85℃ | 50.8*25.4*10.2 |
| FEC15-12S12 | 12 | 9~18 | 86 | 1 | 12/0 | 1.25 | 15 | -40~+85℃ | 50.8*25.4*10.2 |
| FEC15-12S15 | 12 | 9~18 | 86 | 1 | 15/0 | 1 | 15 | -40~+85℃ | 50.8*25.4*10.2 |
| FEC15-12S33 | 12 | 9~18 | 79 | 1 | 3.3/0 | 4 | 13.2 | -40~+85℃ | 50.8*25.4*10.2 |
| FEC15-24D05 | 24 | 18~36 | 84 | 2 | 5/-5 | 1.5 | 15 | -40~+85℃ | 50.8*25.4*10.2 |
| FEC15-24D05W | 24 | 9~36 | 87 | 2 | 5/-5 | 1.5 | 15 | -40~+105℃ | 50.8*25.4*10.2 |
| FEC15-24D12 | 24 | 18~36 | 86 | 2 | 12/-12 | 0.625 | 15 | -40~+85℃ | 50.8*25.4*10.2 |
| FEC15-24D12W | 24 | 9~36 | 88 | 2 | 12/-12 | 0.625 | 15 | -40~+105℃ | 50.8*25.4*10.2 |
| FEC15-24D15 | 24 | 18~36 | 86 | 2 | 15/-15 | 0.5 | 15 | -40~+85℃ | 50.8*25.4*10.2 |
| FEC15-24D15W | 24 | 9~36 | 88 | 2 | 15/-15 | 0.5 | 15 | -40~+105℃ | 50.8*25.4*10.2 |
| FEC15-24S05 | 24 | 18~36 | 84 | 1 | 5/0 | 3 | 15 | -40~+85℃ | 50.8*25.4*10.2 |
| FEC15-24S05W | 24 | 9~36 | 87 | 1 | 5/0 | 3 | 15 | -40~+105℃ | 50.8*25.4*10.2 |
| FEC15-24S12 | 24 | 18~36 | 85 | 1 | 12/0 | 1.25 | 15 | -40~+85℃ | 50.8*25.4*10.2 |
| FEC15-24S12W | 24 | 9~36 | 87 | 1 | 12/0 | 1.25 | 15 | -40~+105℃ | 50.8*25.4*10.2 |
| FEC15-24S15 | 24 | 18~36 | 85 | 1 | 15/0 | 1 | 15 | -40~+85℃ | 50.8*25.4*10.2 |
| FEC15-24S15W | 24 | 9~36 | 87 | 1 | 15/0 | 1 | 15 | -40~+105℃ | 50.8*25.4*10.2 |
| FEC15-24S33 | 24 | 18~36 | 80 | 1 | 3.3/0 | 4 | 13.2 | -40~+85℃ | 50.8*25.4*10.2 |
| FEC15-24S3P3W | 24 | 9~36 | 86 | 1 | 3.3/0 | 4.5 | 14.9 | -40~+105℃ | 50.8*25.4*10.2 |
| FEC15-24S5P1W | 24 | 9~36 | 87 | 1 | 5.1/0 | 3 | 15.3 | -40~+105℃ | 50.8*25.4*10.2 |
| FEC15-48D05 | 48 | 36~75 | 85 | 2 | 5/-5 | 1.5 | 15 | -40~+85℃ | 50.8*25.4*10.2 |
| FEC15-48D05W | 48 | 18~75 | 88 | 2 | 5/-5 | 1.5 | 15 | -40~+105℃ | 50.8*25.4*10.2 |
| FEC15-48D12 | 48 | 36~75 | 88 | 2 | 12/-12 | 0.625 | 15 | -40~+85℃ | 50.8*25.4*10.2 |
| FEC15-48D12W | 48 | 18~75 | 88 | 2 | 12/-12 | 0.625 | 15 | -40~+105℃ | 50.8*25.4*10.2 |
| FEC15-48D15 | 48 | 36~75 | 87 | 2 | 15/-15 | 0.5 | 15 | -40~+85℃ | 50.8*25.4*10.2 |
| FEC15-48D15W | 48 | 18~75 | 88 | 2 | 15/-15 | 0.5 | 15 | -40~+105℃ | 50.8*25.4*10.2 |
| FEC15-48S05 | 48 | 36~75 | 83 | 1 | 5/0 | 3 | 15 | -40~+85℃ | 50.8*25.4*10.2 |
| FEC15-48S05W | 48 | 18~75 | 88 | 1 | 5/0 | 3 | 15 | -40~+105℃ | 50.8*25.4*10.2 |
| FEC15-48S12 | 48 | 36~75 | 87 | 1 | 12/0 | 1.25 | 15 | -40~+85℃ | 50.8*25.4*10.2 |
| FEC15-48S12W | 48 | 18~75 | 87 | 1 | 12/0 | 1.25 | 15 | -40~+105℃ | 50.8*25.4*10.2 |
| FEC15-48S15 | 48 | 36~75 | 86 | 1 | 15/0 | 1 | 15 | -40~+85℃ | 50.8*25.4*10.2 |
| FEC15-48S15W | 48 | 18~75 | 87 | 1 | 15/0 | 1 | 15 | -40~+105℃ | 50.8*25.4*10.2 |
| FEC15-48S33 | 48 | 36~75 | 81 | 1 | 3.3/0 | 4 | 13.2 | -40~+85℃ | 50.8*25.4*10.2 |
| FEC15-48S3P3W | 48 | 18~75 | 86 | 1 | 3.3/0 | 4.5 | 14.9 | -40~+105℃ | 50.8*25.4*10.2 |
| FEC15-48S5P1W | 48 | 18~75 | 88 | 1 | 5.1/0 | 3 | 15.3 | -40~+105℃ | 50.8*25.4*10.2 |
