PSS/PSK系列
产品简介：
PSS, PSK Series Positive Switching Regulators
产品详细：
• Input voltage up to 144 VDC
• Single output of 3.3 to 48 VDC
• No input-to-output isolation
• High efficiency up to 97%
• Extremely wide input voltage range
• Low input-to-output differential voltage
• Very good dynamic properties
• Input undervoltage lockout
• Active current sharing for parallel operation
• Output voltage adjustment, inhibit, and sense lines
• Continuously no-load and short-circuit proof
• All boards are coated with a protective lacquer
- 输入电压:8~144V
- 输出电压:3.3~48V
- 输出功率:61.2~576W
- 尺 寸:171.9X111X60mm
171.9X111X80mm
资料
| 型号 |
标准输入 |
输入电压(V) |
效率(%) |
输出组数 |
输出电压(V) |
输出电流(A) |
输出功率(W) |
工作温度 |
尺寸(mm) |
| PSK1212-7 | 0 | 18~144 | 91 | 1 | 12/0 | 12 | 144 | -40~+71℃ | 171.9*111*60 |
| PSK2412-7 | 0 | 31~144 | 94 | 1 | 24/0 | 12 | 288 | -40~+71℃ | 171.9*111*60 |
| PSK2416-7 | 0 | 29~80 | 94 | 1 | 24/0 | 16 | 384 | -40~+71℃ | 171.9*111*60 |
| PSK2418-2 | 0 | 29~60 | 94 | 1 | 24/0 | 18 | 432 | -40~+71℃ | 171.9*111*60 |
| PSK2420-7 | 0 | 29~80 | 94 | 1 | 24/0 | 20 | 480 | -40~+71℃ | 171.9*111*60 |
| PSK3612-7 | 0 | 44~144 | 96 | 1 | 36/0 | 12 | 432 | -40~+71℃ | 171.9*111*60 |
| PSK3616-7 | 0 | 42~80 | 95 | 1 | 36/0 | 16 | 576 | -40~+71℃ | 171.9*111*60 |
| PSK3620-7 | 0 | 42~80 | 95 | 1 | 36/0 | 20 | 720 | -40~+71℃ | 171.9*111*60 |
| PSK4812-7 | 0 | 58~144 | 97 | 1 | 48/0 | 12 | 576 | -40~+71℃ | 171.9*111*60 |
| PSK5A16-7 | 0 | 8~40 | 79 | 1 | 5.1/0 | 16 | 81.6 | -40~+71℃ | 171.9*111*60 |
| PSK5A18-2 | 0 | 8~40 | 82 | 1 | 5.1/0 | 18 | 91.8 | -40~+71℃ | 171.9*111*60 |
| PSK5A20-7 | 0 | 8~40 | 79 | 1 | 5.1/0 | 20 | 102 | -40~+71℃ | 171.9*111*60 |
| PSK5A25-7 | 0 | 8~40 | 82 | 1 | 5.1/0 | 25 | 127.5 | -40~+71℃ | 171.9*111*60 |
| PSS1212-7 | 0 | 15~80 | 91 | 1 | 12/0 | 12 | 108 | -40~+71℃ | 171.9*111*60 |
| PSS1214-2 | 0 | 16~40 | 90 | 1 | 12/0 | 14 | 144 | -40~+71℃ | 171.9*111*60 |
| PSS1216-7 | 0 | 15~80 | 90 | 1 | 12/0 | 16 | 168 | -40~+71℃ | 171.9*111*60 |
| PSS1218-2 | 0 | 16~40 | 90 | 1 | 12/0 | 18 | 192 | -40~+71℃ | 171.9*111*60 |
| PSS1220-7 | 0 | 15~80 | 90 | 1 | 12/0 | 20 | 240 | -40~+71℃ | 171.9*111*60 |
| PSS129-7 | 0 | 18~144 | 91 | 1 | 12/0 | 9 | 108 | -40~+71℃ | 171.9*111*60 |
| PSS2412-7 | 0 | 29~80 | 94 | 1 | 24/0 | 12 | 288 | -40~+71℃ | 171.9*111*60 |
| PSS2414-2 | 0 | 29~60 | 94 | 1 | 24/0 | 14 | 336 | -40~+71℃ | 171.9*111*60 |
| PSS249-7 | 0 | 31~144 | 94 | 1 | 24/0 | 9 | 216 | -40~+71℃ | 171.9*111*60 |
| PSS3612-7 | 0 | 42~80 | 96 | 1 | 36/0 | 12 | 432 | -40~+71℃ | 171.9*111*60 |
| PSS369-7 | 0 | 44~144 | 96 | 1 | 36/0 | 9 | 324 | -40~+71℃ | 171.9*111*60 |
| PSS489-7 | 0 | 58~144 | 97 | 1 | 48/0 | 9 | 432 | -40~+71℃ | 171.9*111*60 |
| PSS5A12-7 | 0 | 8~80 | 79 | 1 | 5.1/0 | 12 | 61.2 | -40~+71℃ | 171.9*111*60 |
| PSS5A14-2 | 0 | 8~40 | 83 | 1 | 5.1/0 | 14 | 71.4 | -40~+71℃ | 171.9*111*60 |
