AQF1000
产品简介：
AQF100O SERIES AC-DC Switching Power r Supply
产品详细：
. Open Frame 100W Power Supply in 4.0” x 2.0” Size
. High Efficiency up to 93% Typical
. Active PFC Function, >0.95 (230Vac), >0.99 (115Vac)
. Universal Input: 90-264 VAC
. 100W Full Load at 50°C Under Free Air Convection
. 120W with FAN (20CFM / 300LFM)
. Low Leakage Current, <250uA
. EN55022 Class B Meets
. Class I and Class II Construction
. Continuous Short Circuit Protection with Hiccup Mode and Auto Recover
. 3-Years Product Warranty
- 输入电压:90-264 V
- 输出电压:12V/15V/24V/48V
- 输出功率:100W
- 尺 寸:103.9 x 52.1 x 25.0 mm
