FEC40/FEC40W
产品简介：
台湾博大P-DUKE FEC40/FEC40W系列DC/DC电源模块,输入电压:12/24V/48V ,单路,双路,三路输出电压供选择,输出功率12-40W,效率达90%
产品详细：
台湾博大P-DUKE FEC40/FEC40W系列DC/DC电源模块
输入电压:12/24V/48V
单路,双路,三路输出电压供选择
输出功率12-40W,效率达90%
2:1(FEC40),4:1(FEC40W)输入电压范围,遥控功能
输入欠压关闭,连续短路保护
工作温度范围-40℃至85℃(FEC40),-40℃至105℃(FEC40W),
金属外壳绝缘底座,六面EMI/RFI屏蔽外
型尺寸:50.8mm(长)x50.8mm(宽)x10.16mm(高)
- 输入电压:9-18V
18-36V(9-36V)
36-75V(18-75V)
- 输出电压:1.5V/1.8V/2.5V/
3.3V/5V/12V/15V/
±12V/±15V
- 输出功率:12-40W
- 尺 寸:50.8*50.8*10.2
资料 资料
| 型号 |
标准输入 |
输入电压(V) |
效率(%) |
输出组数 |
输出电压(V) |
输出电流(A) |
输出功率(W) |
工作温度 |
尺寸(mm) |
| FEC40-12D12 | 12 | 9~18 | 85 | 2 | 12/-12 | 1.8 | 43 | -40~+85℃ | 50.8*50.8*10.2 |
| FEC40-12D15 | 12 | 9~18 | 85 | 2 | 15/-15 | 1.4 | 42 | -40~+85℃ | 50.8*50.8*10.2 |
| FEC40-12D3305 | 12 | 9~18 | 85 | 2 | 3.3/5 | 4 | 33.2 | -40~+85℃ | 50.8*50.8*10.2 |
| FEC40-12S05 | 12 | 9~18 | 86 | 1 | 5/0 | 8 | 40 | -40~+85℃ | 50.8*50.8*10.2 |
| FEC40-12S12 | 12 | 9~18 | 86 | 1 | 12/0 | 3.333 | 40 | -40~+85℃ | 50.8*50.8*10.2 |
| FEC40-12S15 | 12 | 9~18 | 87 | 1 | 15/0 | 2.66 | 40 | -40~+85℃ | 50.8*50.8*10.2 |
| FEC40-12S1P5 | 12 | 9~18 | 84 | 1 | 1.5/0 | 8 | 12 | -40~+85℃ | 50.8*50.8*10.2 |
| FEC40-12S1P8 | 12 | 9~18 | 82 | 1 | 1.8/0 | 8 | 14.4 | -40~+85℃ | 50.8*50.8*10.2 |
| FEC40-12S2P5 | 12 | 9~18 | 84 | 1 | 2.5/0 | 8 | 20 | -40~+85℃ | 50.8*50.8*10.2 |
| FEC40-12S3P3 | 12 | 9~18 | 86 | 1 | 3.3/0 | 8 | 26.4 | -40~+85℃ | 50.8*50.8*10.2 |
| FEC40-12T0512 | 12 | 9~18 | 86 | 3 | 5/12 | 6 | 39.6 | -40~+85℃ | 50.8*50.8*10.2 |
| FEC40-12T0515 | 12 | 9~18 | 86 | 3 | 5/15 | 6 | 39 | -40~+85℃ | 50.8*50.8*10.2 |
| FEC40-12T3312 | 12 | 9~18 | 84 | 3 | 3.3/12 | 6 | 29.4 | -40~+85℃ | 50.8*50.8*10.2 |
| FEC40-12T3315 | 12 | 9~18 | 84 | 3 | 3.3/15 | 6 | 28.8 | -40~+85℃ | 50.8*50.8*10.2 |
| FEC40-24D12 | 24 | 18~36 | 87 | 2 | 12/-12 | 1.8 | 43 | -40~+85℃ | 50.8*50.8*10.2 |
| FEC40-24D12W | 24 | 9~36 | 86 | 2 | 12/-12 | 1.667 | 40 | -40~+105℃ | 50.8*50.8*10.2 |
| FEC40-24D15 | 24 | 18~36 | 87 | 2 | 15/-15 | 1.4 | 42 | -40~+85℃ | 50.8*50.8*10.2 |
| FEC40-24D15W | 24 | 9~36 | 86 | 2 | 15/-15 | 1.333 | 40 | -40~+105℃ | 50.8*50.8*10.2 |
| FEC40-24D3305 | 24 | 18~36 | 86 | 2 | 3.3/5 | 4 | 33.2 | -40~+85℃ | 50.8*50.8*10.2 |
| FEC40-24S05 | 24 | 18~36 | 89 | 1 | 5/0 | 8 | 40 | -40~+85℃ | 50.8*50.8*10.2 |
| FEC40-24S05W | 24 | 9~36 | 87 | 1 | 5/0 | 8 | 40 | -40~+105℃ | 50.8*50.8*10.2 |
| FEC40-24S12 | 24 | 18~36 | 88 | 1 | 12/0 | 3.333 | 40 | -40~+85℃ | 50.8*50.8*10.2 |
| FEC40-24S12W | 24 | 9~36 | 87 | 1 | 12/0 | 3.333 | 40 | -40~+105℃ | 50.8*50.8*10.2 |
| FEC40-24S15 | 24 | 18~36 | 89 | 1 | 15/0 | 2.666 | 40 | -40~+85℃ | 50.8*50.8*10.2 |
| FEC40-24S15W | 24 | 9~36 | 87 | 1 | 15/0 | 2.666 | 40 | -40~+105℃ | 50.8*50.8*10.2 |
| FEC40-24S1P5 | 24 | 18~36 | 81 | 1 | 1.5/0 | 8 | 12 | -40~+85℃ | 50.8*50.8*10.2 |
| FEC40-24S1P8 | 24 | 18~36 | 83 | 1 | 1.8/0 | 8 | 14.4 | -40~+85℃ | 50.8*50.8*10.2 |
| FEC40-24S2P5 | 24 | 18~36 | 86 | 1 | 2.5/0 | 8 | 20 | -40~+85℃ | 50.8*50.8*10.2 |
| FEC40-24S3P3 | 24 | 18~36 | 87 | 1 | 3.3/0 | 8 | 26.4 | -40~+85℃ | 50.8*50.8*10.2 |
| FEC40-24S3P3W | 24 | 9~36 | 86 | 1 | 3.3/0 | 10 | 33 | -40~+105℃ | 50.8*50.8*10.2 |
| FEC40-24T0512 | 24 | 18~36 | 87 | 3 | 5/12 | 6 | 39.6 | -40~+85℃ | 50.8*50.8*10.2 |
| FEC40-24T0515 | 24 | 18~36 | 87 | 3 | 5/15 | 6 | 39 | -40~+85℃ | 50.8*50.8*10.2 |
| FEC40-24T3312 | 24 | 18~36 | 85 | 3 | 3.3/12 | 6 | 29.4 | -40~+85℃ | 50.8*50.8*10.2 |
| FEC40-24T3315 | 24 | 18~36 | 85 | 3 | 3.3/15 | 6 | 28.8 | -40~+85℃ | 50.8*50.8*10.2 |
| FEC40-48D12 | 48 | 36~75 | 87 | 2 | 12/-12 | 1.8 | 43 | -40~+85℃ | 50.8*50.8*10.2 |
| FEC40-48D12W | 48 | 18~75 | 86 | 2 | 12/-12 | 1.667 | 40 | -40~+105℃ | 50.8*50.8*10.2 |
| FEC40-48D15 | 48 | 36~75 | 87 | 2 | 15/-15 | 1.4 | 42 | -40~+85℃ | 50.8*50.8*10.2 |
| FEC40-48D15W | 48 | 18~75 | 86 | 2 | 15/-15 | 1.333 | 40 | -40~+105℃ | 50.8*50.8*10.2 |
| FEC40-48D3305 | 48 | 36~75 | 88 | 2 | 3.3/5 | 4 | 33.2 | -40~+85℃ | 50.8*50.8*10.2 |
| FEC40-48S05 | 48 | 36~75 | 90 | 1 | 5/0 | 8 | 40 | -40~+85℃ | 50.8*50.8*10.2 |
| FEC40-48S05W | 48 | 18~75 | 88 | 1 | 5/0 | 8 | 40 | -40~+105℃ | 50.8*50.8*10.2 |
| FEC40-48S12 | 48 | 36~75 | 89 | 1 | 12/0 | 3.333 | 40 | -40~+85℃ | 50.8*50.8*10.2 |
| FEC40-48S12W | 48 | 18~75 | 87 | 1 | 12/0 | 3.333 | 40 | -40~+105℃ | 50.8*50.8*10.2 |
| FEC40-48S15 | 48 | 36~75 | 89 | 1 | 15/0 | 2.666 | 40 | -40~+85℃ | 50.8*50.8*10.2 |
| FEC40-48S15W | 48 | 18~75 | 87 | 1 | 15/0 | 2.666 | 40 | -40~+105℃ | 50.8*50.8*10.2 |
| FEC40-48S1P5 | 48 | 36~75 | 82 | 1 | 1.5/0 | 8 | 12 | -40~+85℃ | 50.8*50.8*10.2 |
| FEC40-48S1P8 | 48 | 36~75 | 84 | 1 | 1.8/0 | 8 | 14.4 | -40~+85℃ | 50.8*50.8*10.2 |
| FEC40-48S2P5 | 48 | 36~75 | 86 | 1 | 2.5/0 | 8 | 20 | -40~+85℃ | 50.8*50.8*10.2 |
| FEC40-48S3P3 | 48 | 36~75 | 88 | 1 | 3.3/0 | 8 | 26.4 | -40~+85℃ | 50.8*50.8*10.2 |
| FEC40-48S3P3W | 48 | 18~75 | 86 | 1 | 3.3/0 | 10 | 33 | -40~+105℃ | 50.8*50.8*10.2 |
| FEC40-48T0512 | 48 | 36~75 | 88 | 3 | 5/12 | 6 | 39.6 | -40~+85℃ | 50.8*50.8*10.2 |
| FEC40-48T0515 | 48 | 36~75 | 88 | 3 | 5/15 | 6 | 39 | -40~+85℃ | 50.8*50.8*10.2 |
| FEC40-48T3312 | 48 | 36~75 | 86 | 3 | 3.3/12 | 6 | 29.4 | -40~+85℃ | 50.8*50.8*10.2 |
| FEC40-48T3315 | 48 | 36~75 | 86 | 3 | 3.3/15 | 6 | 28.8 | -40~+85℃ | 50.8*50.8*10.2 |
