产品简介：
产品详细：
- 输入电压:50-730V
- 输出电压:15V/0.05A
- 输出功率:12-18W
- 尺 寸:
| 型号 |
标准输入 |
输入电压(V) |
效率(%) |
输出组数 |
输出电压(V) |
输出电流(A) |
输出功率(W) |
工作温度 |
尺寸(mm) |
| PMT12-051208 | 0 | 85~650 | 0 | 3 | 5/12 | 1 | 12 | -40~70℃ | 80*40*35 |
| PMT12-051208A | 0 | 65~650 | 0 | 3 | 5.3/12 | 1 | 12 | -40~70℃ | 80*40*35 |
| PMT12-051412 | 0 | 65~650 | 0 | 3 | 5/13.5 | 0.6 | 12 | -40~70℃ | 80*40*35 |
| PMT12-061212 | 0 | 65~650 | 0 | 3 | 5.8/12 | 1 | 12 | -40~70℃ | 80*40*35 |
| PMT12-061312A | 0 | 65~650 | 0 | 3 | 5.8/12.5 | 1 | 12 | -40~70℃ | 80*40*35 |
| PMT12-120808 | 0 | 50~730 | 0 | 3 | 12/8 | 0.3 | 12 | -40~70℃ | 80*40*35 |
| PMT12-1212 | 0 | 100~650 | 0 | 2 | 12.5/12 | 1 | 12 | -40~70℃ | 80*40*35 |
| PMT12-121208 | 0 | 120~650 | 0 | 3 | 12/8 | 1 | 12 | -40~70℃ | 80*40*35 |
| PMT12-121412 | 0 | 85~650 | 0 | 3 | 12/13.5 | 0.3 | 12 | -40~70℃ | 80*40*35 |
| PMT12-121508 | 0 | 85~650 | 0 | 3 | 12/15 | 0.3 | 12 | -40~70℃ | 80*40*35 |
| PMT12-1312 | 0 | 100~650 | 0 | 2 | 13/12 | 1 | 12 | -40~70℃ | 80*40*35 |
| PMT18-0511612A | 0 | 65~650 | 0 | 3 | 5/16 | 1.2 | 18 | -40~70℃ | 100*50*35 |
| PMT18-051212R | 0 | 65~650 | 0 | 3 | 5/12 | 1.2 | 18 | -40~70℃ | 100*50*35 |
| PMT18-051212RE | 0 | 65~650 | 0 | 3 | 5.4/12 | 1.2 | 18 | -40~70℃ | 100*50*35 |
| PMT18-051312 | 0 | 65~650 | 0 | 3 | 5/13.5 | 1.5 | 18 | -40~70℃ | 100*50*35 |
| PMT18-051312A2 | 0 | 65~650 | 0 | 3 | 5/13.5 | 1.5 | 18 | -40~70℃ | 100*50*35 |
| PMT18-051312E2 | 0 | 65~650 | 0 | 3 | 5/13.5 | 1.5 | 18 | -40~70℃ | 100*50*35 |
| PMT18-051313A | 0 | 65~650 | 0 | 3 | 5.6/13 | 1.5 | 18 | -40~70℃ | 100*50*35 |
| PMT18-051313A2 | 0 | 85~650 | 0 | 3 | 5.6/13 | 1.5 | 18 | -40~70℃ | 100*50*35 |
| PMT18-051412 | 0 | 85~650 | 0 | 3 | 5/13.5 | 1 | 18 | -40~70℃ | 100*50*35 |
| PMT18-053608 | 0 | 100~650 | 0 | 3 | 5/36 | 0.8 | 18 | -40~70℃ | 100*50*35 |
| PMT18-061212 | 0 | 65~650 | 0 | 3 | 5.8/12 | 1.2 | 18 | -40~70℃ | 100*50*35 |
| PMT18-061412A2 | 0 | 65~650 | 0 | 3 | 6.3/14 | 1.2 | 18 | -40~70℃ | 100*50*35 |
| PMT18-121412 | 0 | 65~650 | 0 | 3 | 12/13.5 | 0.6 | 18 | -40~70℃ | 100*50*35 |
| PMT18-121412A | 0 | 65~650 | 0 | 3 | 12/13.5 | 0.2 | 18 | -40~70℃ | 100*50*35 |
| PMT18-151412 | 0 | 65~650 | 0 | 3 | 15/13.5 | 0.5 | 18 | -40~70℃ | 100*50*35 |
| PMT18A-051212 | 0 | 65~650 | 0 | 3 | 5.3/12 | 1.5 | 18 | -40~70℃ | 100*50*35 |
| PMT18A-051212R | 0 | 65~650 | 0 | 3 | 5.2/12 | 1.5 | 18 | -40~70℃ | 100*50*35 |
| PMT18A-051312 | 0 | 65~650 | 0 | 3 | 5.3/13.5 | 1.5 | 12 | -40~70℃ | 100*50*35 |
| PMT18A-051512 | 0 | 65~650 | 0 | 3 | 5/15 | 1.5 | 18 | -40~70℃ | 100*50*35 |
| PMT18A-121208 | 0 | 65~650 | 0 | 3 | 12/12 | 1 | 18 | -40~70℃ | 100*50*35 |
| PMT18B-061212A | 0 | 65~700 | 0 | 3 | 5.8/12 | 1 | 18 | -40~70℃ | 100*50*35 |
