LCD20/LCD20W
产品简介：
LCD20/LCD20W SERIES 20 WATTS DC-DC CONVERTER
产品详细：
• 20 WATTS MAXIMUM OUTPUT POWER
• ULTRA LOW QUIESCENT CURRENT
• SINGLE OUTPUT UP TO 4.5A
• SMALL SIZE AND LOW PROFILE：1.0 x 1.0 x 0.39 INCH
• HIGH EFFICIENCY UP TO 91%
• 2:1 WIDE INPUT VOLTAGE RANGE
• SIX-SIDED CONTINUOUS SHIELD
• MEET EN55022 CLASS A WITHOUT EXTERNAL COMPONENTS
• FIXED SWITCHING FREQUENCY
• INPUT TO OUTPUT ISOLATION:1600VDC
• INDUSTRY STANDARD PIN-OUT LCD15 SERIES COMPATIBLE
• CE MARK MEETS 2006/95/EC, 2011/95/EC AND 2004/108/EC
• SAFETY MEETS UL60950-1, EN60950-1 AND IEC60950-1
• COMPLIANT TO RoHS EU DIRECTIVE 2011/65/EU
- 输入电压:9-75V
- 输出电压:3.3V/5V/12V/15V
- 输出功率:20W
- 尺 寸:25.4 X 25.4 X 9.9mm
