PDH03W/PDS03W
产品简介：
PDS(H)03W SERIES 3 WATTS DC-DC CONVERTER
产品详细：
• 3 WATTS MAXIMUM OUTPUT POWER
• SMD AND DIP PACKAGE, 0.74 x 0.50 x 0.33 INCH
• SMD PACKAGE QUALIFIED FOR LEADFREE REFLOW SOLDER PROCESS ACCORDING IPC J-STD-020D
• 4:1 ULTRA WIDE INPUT VOLTAGE RANGE
• HIGH EFFICIENCY UP TO 83%
• 1600VDC INPUT TO OUTPUT ISOLATION AND 3000VDC FOR OPTION
• LOW RIPPLE & NOISE
• EXTERNAL ON/OFF CONTROL
• SWITCHING FREQUENCY (100kHz, MIN)
• CONTINUOUS SHORT CIRCUIT PROTECTION
• UL94-V0 PACKAGE MATERIALS
• CE MARK MEETS 2006/95/EC, 2011/95/EC AND 2004/108/EC
• SAFETY MEETS UL60950-1, EN60950-1 AND IEC60950-1
• COMPLIANT TO RoHS EU DIRECTIVE 2011/65/EU
- 输入电压:4.5-75V
- 输出电压:3W
- 输出功率:3W
- 尺 寸:18.9 X 12.8 X 8.4 mm
